Power Conditioning.

prod1

Description / Specification of Power Conditioning.

We are involved in offering a wide range of Power Conditioning. to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Power Conditioning.. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design



.



Request A Quote      Back

Passive Harmonic Filter

prod1

Most of the mentioned filtering techniques have common draw back of higher cost compared to passive filtering techniques. Consequently, the passive harmonic filtering techniques to a large extent are still the most commonly used techniques for current harmonics mitigation of 6-pulse front-end diode rectifier
application.
Here in ACE we have developed an efficient passive broadband filter, which can suit many similar of loads. Since all filter components are passive they are rugged, maintenance free, reliable and low cost. Moreover, the filter implementation procedure is relatively easy.

.



Request A Quote      Back

Detuned Reactors

prod1

ACE detuned reactors are high quality reactors designed to be used in detuned power factor correction.
ACE has a standard range of reactors with P=7% which means a resonance frequency of 189Hz for 50Hz networks or 227Hz for 60H networks.
Reduce over heating of transformer.
Reduce the harmonic current in the electrical system.
Improves the life of capacitors by reducing Overheating or fuse failure.

.



Request A Quote      Back

Ace Statcom Static Compensator

prod1

Introduction :
The STATCOM is an electronically generated three - phase voltage source that is connected to the AC system. When operating as a pure STATCOM the generated voltage is exactly in phase with the AC system voltage. If the generated voltage is greater than the terminal voltage then the device will supply VARs (i.e. is capacitive) to the system. If the internal voltage is less than the terminal voltage, the device will absorb VARS (i.e. is inductive) from the system. The control system of the STATCOM is extremely fast and therefore can rapidly change the magnitude (and phase) of the electronically generated voltage.

.



Request A Quote      Back

Static Stabilizers

prod1

Features :
  1. ACE Static Stabilizer has got direct AC-AC conversion without rectifying to DC improves the efficiency, reliability and reduces the components.
  2. ACE Static Stabilizer’s Output regulation of +/- 1% which is impossible in conventional stabilizer.
  3. Compact size and lightweight.
  4. Very fast switching response as compared to the conventional stabilizer.
  5. Fully solid state. No moving part, hence more life and no maintenance.
  6. Small transformer size (1/5th of the capacity).
  7. IGBT based system. So highly reliable and efficient.
  8. Silent operation.

.



Request A Quote      Back

Active Harmonic Filters

prod1

Features :
  1. Shunt Active Harmonic Filter is an IGBT PWM Converter which dynamically conditions your current distortion (THDi) less than 5 mSecs.
  2. Distortion Factor i.e. THDi = KWH/(Power Factor * KVAH)
  3. Reduction harmonics can lead to unity power factor.
  4. No burning of Neutrals – Reduction in I²R Losses.
  5. Reduction of transmission losses.
  6. Shunt Active Harmonic Filter results into THDi < 10%

.



Request A Quote      Back

Ace Thyristor Pfc Modules

prod1

Features :
  1. Thyristor PFC Module is Thyristor based switching module, which can be used in APFC panels in place of contactors, as contactors will draw a large amount of inrush current to Capacitors.
  2. Zero current crossing of thyristor helps to minimize the inrush current.
  3. Should be used along with the detuned reactors for optimum results.
  4. Two types of modules we are offering :
    a) Zero Current Crossing &
    b) ACE Precise Zero Current Crossing.
  5. Longer lifetime.

.



Request A Quote      Back
