The unique “Double Break” main contact system ensures extremely fast interruption of short circuit currents and substantially reduces main contact wear. The internally symmetrical “Double Break” structure allow reverse power connection. This is the only ACB with this facility in India that only provided by BCH Air Circuit Breaker Manufacturer.

Our Resilient range of MCCB is available in two frame sizes with standard and high performance variants. As the name Resilient implies, the product in this range have been designed and tested to perform excellently in harsh Indian conditions.

MCCB : Moulded Case Circuit Breakers

Switch Disconnector Fuse

Conforms to IS/IEC 60947-3
TPN/TP version
AC 23A duty
Mechanism with 4 Breaks per pole
Handle with door interlock and padlock

Flexibility of Installation

Line load interchangeability
Suitable for isolation
Suitable for IT systems
Current limiting design
45mm panel cutout, suitable for standard MCB
distribution boards
Possibility of bus bar termination at both ends

Auto Start direct on line starter

Automatically starts the motor when the power comes back after a failure up to 24 a relay rating
Time delay before restart to allow time for settling of power supply fluctuations
Monitors power supply condition before restarting
Protection against single phasing, phase imbalance & phase reversal

Direct on line : upto 24 A relay rating
Star Delta : upto 39 A relay rating
Protections against :

Phase failure
Phase imbalance
Phase reversal

Short Circuit Protection through MCB :- In case of Premium models
Ammeter and Voltmeter
On/Off and Trip indications
Powder coated enclosure with PU gasket ensures excellent finish and reliability
Provision for connecting dry run preventer

Oil Immersed Starters

Features

Completely modular in all three axis
Powder coated surface (RAL 7035) provides for excellent finish and durability
PU Gasket ensures higher degree of ingress protection

Key attributes:

Aesthetic & robust construction
Mounting fan /s in top do not occupy usable “U” space.
Special wallmounting hardware.
Provision for earthing available in the cabinets.
Highly corrosion resistant in nature.
Powder coated to shade RAL : 7035 structure finish.

Range

51 different versions

Single/Double door versions

Min. Size : 200mm x 200mm x 150mm

Max Size : 1000mm x 1200mm x 300mm

Latest design concepts & manufacturing processes.
Form 3b for standard MCC & PCC construction.
Unique techno modular construction with CRCA sheet steel.
Fully compartmentalized.
Suitable for indoor installations.
Fixed Type – available in single / double front execution.
Draw Out Type – available in single front / double front execution.
PU Foam gasket – can withstand temperatures from-40C to +120C.
10 Tank spray based tricationic phosphating treatment – unique in the industry.
Powder Coating with RAL7032 (default) or other user specified structure finish for enclosures.
RAL 2000 finish or galvanized mounting plate options avaiable.
IP: 54 & IP: 55 protection offered as per IS: 13947.
Up-to 4000A, 50kA horizontal bur bars with E91E grade Aluminium / Copper bus bars.
Aluminium E91E grade vertical bus bars / higher ratings with electrolytic grade copper bus bars.
Short Circuit withstand capability tested at CPRI – busbar system suitable for 50kA for 1 sec. & 105kA peak.
All tailor made solutions available on request & based on specific enquiries. Contact nearest branch location for detailed proposal to meet your exact requirements.

This controller provides reversing and plugging operation of slip ring induction motors in heavy duty cranes on trolley services. Upto 5 motor speeds are achievable when used in conjunction with a master controller.

Features

Special Chromium Steel Alloy (AISI406) used for :
a) Higher resistivity (approximately 70% higher than others)Results in overall lighter and compacter unit
b) Low temperature coefficient (approx 72% lower than others) leading tonegligible change in resistance values despite grid temperature variations ( avery important parameter in applications such as crane controls)

Range

Single / Multiple outlet boxes
16/32/63/125A rating
With or without protection
Option of back up protection with :

MCBs
SDFUs
MCCBs

Modular and compact construction
Loop in Loop out facility
Higher degree of ingress protection
7 Tank processed powder coated enclosure
PV gasketing for excellent sealing against dust and water

Advantages

Good starting torque and current performance
Possibility of adjusting starting parameters
No break in supply to the motor during starting
Best suited for cases when either maximum reduction of Inrush current is desired or motor requires longer acceleration time with good starting torque,such as:

Blowers
Pumps
Compressors
Extruders
Crushers

Metallized Polypropylene MPP

1 to 50 KVAR
440/ 480 / 525 VAC
Self healing
Reference standard (IS 13440: 1993)
Dry resin can type Normal to Heavy duty
Box Type Normal to Heavy duty
1 Watts / KVAR total losses

RG-T series are for compensation of balanced loads. RG3-T series are ultimate solution for compensation of unbalanced loads. The compensation is realized by the reactive power of the system through 3 current transformers from 3 phases. This makes RG3-T series a unique solution for unbalanced load compensation .
